Documentation for ATIS-Draft-03-00-79

Super-types:	None
Sub-types:	None

Name	WeatherInformation
Used by (from the same schema document)	Complex Type ResponseGroup , Complex Type SubRoute
Abstract	no

XML Instance Representation

<...>

<head> Head </head> [0..1]

<location> lrms:LocationReference </location> [0..1]

Start Choice [0..1]

<altLoc> lrms:AdminAreaGroup </altLoc> [1]

<lat-long> LocationPoint </lat-long> [1]

End Choice

<elevationsAbove> lrms:Height </elevationsAbove> [0..1]

<elevationsBelow> lrms:Height </elevationsBelow> [0..1]

<isForecast> xs:boolean </isForecast> [0..1]

<coverageTime> ComplexTime </coverageTime> [0..1]

<forecastExpires> DateTimePair </forecastExpires> [0..1]

<tempSummary> itis:Temperature </tempSummary> [0..1]

<tempQualifers> itis:Qualifiers </tempQualifers> [0..1]

<highTemp> ntcip:EssMaxTemp </highTemp> [0..1]

<lowTemp> ntcip:EssMinTemp </lowTemp> [0..1]

<currTemp> ntcip:EssAirTemperature </currTemp> [0..1]

<conditions> itis:WeatherConditions </conditions> [0..1]

<sunriseTime> Time </sunriseTime> [0..1]

<sunsetTime> Time </sunsetTime> [0..1]

<skyConditions> Weather-SkyConditions </skyConditions> [0..1]

<cloudPercent> ntcip:EssCloudSituation </cloudPercent> [0..1]

<visibilityLevel> itis:VisibilityAndAirQuality </visibilityLevel> [0..1]

<visibilityQualifier> itis:Qualifiers </visibilityQualifier> [0..1]

<visibility> ntcip:EssVisibility </visibility> [0..1]

<windsType> itis:Winds </windsType> [0..1]

<windDirection> CompassDirection </windDirection> [0..1]

<windAngle> ntcip:EssAvgWindDirection </windAngle> [0..1]

<windSpeed> ntcip:EssAvgWindSpeed </windSpeed> [0..1]

<windGustSpeed> ntcip:EssAvgWindSpeed </windGustSpeed> [0..1]

<precipitationProbability> Percent </precipitationProbability> [0..1]

<precipitation> itis:Precipitation </precipitation> [0..1]

<humidity> ntcip:EssRelativeHumidity </humidity> [0..1]

<snowDepth> ntcip:EssRoadwaySnowDepth </snowDepth> [0..1]

<snowPack> ntcip:EssRoadwaySnowPackDepth </snowPack> [0..1]

<snowFall> ntcip:EssSnowfallAccumRate </snowFall> [0..1]

<snowOffRoad> ntcip:EssAdjacentSnowDepth </snowOffRoad> [0..1]

<iceThickness> ntcip:EssIceThickness </iceThickness> [0..1]

<blackIce> ntcip:EssSurfaceBlackIceSignal </blackIce> [0..1]

<freezePoint> ntcip:EssSurfaceFreezePoint </freezePoint> [0..1]

<rain24hrs> ntcip:EssPrecipitation24Hours </rain24hrs> [0..1]

<rain1hr> ntcip:EssPrecipitationOneHour </rain1hr> [0..1]

<rainRate> ntcip:EssPrecipRate </rainRate> [0..1]

<precipSituation> ntcip:EssPrecipSituation </precipSituation> [0..1]

<precipYesNo> ntcip:EssPrecipYesNo </precipYesNo> [0..1]

<waterDepth> ntcip:EssWaterDepth </waterDepth> [0..1]

<surfaceWaterDepth> ntcip:EssSurfaceWaterDepth </surfaceWaterDepth> [0..1]

<precipStart> DateTimePair </precipStart> [0..1]

<precipEnd> DateTimePair </precipEnd> [0..1]

<smogAlert> Pollution-SmogAlert </smogAlert> [0..1]

<airQualityIndex> Pollution-AirQualityIndex </airQualityIndex> [0..1]

<carbonMonoxide> ntcip:EssCO </carbonMonoxide> [0..1]

<carbonDioxide> ntcip:EssCO2 </carbonDioxide> [0..1]

<hydroCarbon> Pollution-HydroCarbon </hydroCarbon> [0..1]

<sulfurDioxide> ntcip:EssSO2 </sulfurDioxide> [0..1]

<nitricOxide> ntcip:EssNO </nitricOxide> [0..1]

<nitrousDioxide> ntcip:EssNO2 </nitrousDioxide> [0..1]

<particulate> ntcip:EssPM10 </particulate> [0..1]

<ozone> ntcip:EssO3 </ozone> [0..1]

<uvLevel> UVLevel </uvLevel> [0..1]

<airQuality> itis:VisibilityAndAirQuality </airQuality> [0..1]

<airQualifier> itis:Qualifiers </airQualifier> [0..1]

<levelofservice> tmdd:Link-level-of-service </levelofservice> [0..1]

<status> itis:Closures </status> [0..1]

<drivingRestrictions> itis:WinterDrivingRestrictions </drivingRestrictions> [0..1]

<drivingIndex> itis:WinterDrivingIndex </drivingIndex> [0..1]

<mediantype> tmdd:Link-median-type </mediantype> [0..1]

<mobileFriction> ntcip:EssMobileFriction </mobileFriction> [0..1]

<pavementConditions> itis:PavementConditions </pavementConditions> [0..3]

<pavementTemperature> ntcip:EssPavementTemperature </pavementTemperature> [0..1]

<surfaceTemperature> ntcip:EssSurfaceTemperature </surfaceTemperature> [0..1]

<surfaceSalinity> ntcip:EssSurfaceSalinity </surfaceSalinity> [0..1]

<pavementtype> tmdd:Link-pavement-type </pavementtype> [0..1]

<treatmentForm> ntcip:EssPaveTreatProductForm </treatmentForm> [0..1]

<treatmentType> ntcip:EssPaveTreatProductType </treatmentType> [0..1]

<treatmentAmount> ntcip:EssPaveTreatmentAmount </treatmentAmount> [0..1]

<treatmentWidth> ntcip:EssPaveTreatmentWidth </treatmentWidth> [0..1]

<pressure> ntcip:EssAtmosphericPressure </pressure> [0..1]

<solarRate> ntcip:EssSolarRadiation </solarRate> [0..1]

<dewPoint> ntcip:EssDewpointTemp </dewPoint> [0..1]

<other> ntcip:ESS-other </other> [0..1]

<furtherText> xs:string (length >= 1) </furtherText> [0..1]

<furtherData> URL-Link </furtherData> [0..1]

<tail> Tail </tail> [0..1]

<localWeatherInformation> local:WeatherInformation </localWeatherInformation> [0..1]

</...>

Schema Component Representation

<xs:complexType name="WeatherInformation">

<xs:sequence>

<xs:element name="head" type=" Head " minOccurs="0"/>

<xs:element name="location" type=" lrms:LocationReference " minOccurs="0"/>

<-- location for which this applies -->

<xs:choice minOccurs="0">

<xs:element name="altLoc" type=" lrms:AdminAreaGroup "/>

<-- Simple named places -->

<xs:element name="lat-long" type=" LocationPoint "/>

<-- Point and raduis locations -->

</xs:choice>

<-- This may be used as an alt loc method -->

<xs:element name="elevationsAbove" type=" lrms:Height " minOccurs="0"/>

<xs:element name="elevationsBelow" type=" lrms:Height " minOccurs="0"/>

<-- remainder of message content is applied to elevations above or below these amounts if they are present -->

<xs:element name="isForecast" minOccurs="0">

<xs:simpleType>

<xs:restriction base=" xs:boolean "/>

</xs:simpleType>

</xs:element>

<-- forecast or predicted period -->

<xs:element name="coverageTime" type=" ComplexTime " minOccurs="0"/>

<xs:element name="forecastExpires" type=" DateTimePair " minOccurs="0"/>

<-- temperatures -->

<xs:element name="tempSummary" type=" itis:Temperature " minOccurs="0"/>

<xs:element name="tempQualifers" type=" itis:Qualifiers " minOccurs="0"/>

<xs:element name="highTemp" type=" ntcip:EssMaxTemp " minOccurs="0"/>

<-- in tenths of degrees C -->

<xs:element name="lowTemp" type=" ntcip:EssMinTemp " minOccurs="0"/>

<-- in tenths of degrees C -->

<xs:element name="currTemp" type=" ntcip:EssAirTemperature " minOccurs="0"/>

<-- in tenths of degrees C sky, wind, and sun conditions -->

<xs:element name="conditions" type=" itis:WeatherConditions " minOccurs="0"/>

<-- gross conditions -->

<xs:element name="sunriseTime" type=" Time " minOccurs="0"/>

<xs:element name="sunsetTime" type=" Time " minOccurs="0"/>

<xs:element name="skyConditions" type=" Weather-SkyConditions " minOccurs="0"/>

<-- ITIS codes -->

<xs:element name="cloudPercent" type=" ntcip:EssCloudSituation " minOccurs="0"/>

<xs:element name="visibilityLevel" type=" itis:VisibilityAndAirQuality " minOccurs="0"/>

<-- visablity limits -->

<xs:element name="visibilityQualifier" type=" itis:Qualifiers " minOccurs="0"/>

<xs:element name="visibility" type=" ntcip:EssVisibility " minOccurs="0"/>

<-- in tenths of a meter -->

<xs:element name="windsType" type=" itis:Winds " minOccurs="0"/>

<-- similar to NTCIP.EssWindSituation -->

<xs:element name="windDirection" type=" CompassDirection " minOccurs="0"/>

<-- in compass point phrases -->

<xs:element name="windAngle" type=" ntcip:EssAvgWindDirection " minOccurs="0"/>

<-- expressed in degrees -->

<xs:element name="windSpeed" type=" ntcip:EssAvgWindSpeed " minOccurs="0"/>

<-- tenths of meters per sec -->

<xs:element name="windGustSpeed" type=" ntcip:EssAvgWindSpeed " minOccurs="0"/>

<-- tenths of meters per sec water, rain, ice, snow events -->

<xs:element name="precipitationProbability" type=" Percent " minOccurs="0"/>

<-- quality of this information -->

<xs:element name="precipitation" type=" itis:Precipitation " minOccurs="0"/>

<xs:element name="humidity" type=" ntcip:EssRelativeHumidity " minOccurs="0"/>

<-- percent. -->

<xs:element name="snowDepth" type=" ntcip:EssRoadwaySnowDepth " minOccurs="0"/>

<-- in centimeters -->

<xs:element name="snowPack" type=" ntcip:EssRoadwaySnowPackDepth " minOccurs="0"/>

<-- in centimeters -->

<xs:element name="snowFall" type=" ntcip:EssSnowfallAccumRate " minOccurs="0"/>

<-- in centimeters -->

<xs:element name="snowOffRoad" type=" ntcip:EssAdjacentSnowDepth " minOccurs="0"/>

<-- in centimeters -->

<xs:element name="iceThickness" type=" ntcip:EssIceThickness " minOccurs="0"/>

<-- in millimeters -->

<xs:element name="blackIce" type=" ntcip:EssSurfaceBlackIceSignal " minOccurs="0"/>

<-- in millimeters -->

<xs:element name="freezePoint" type=" ntcip:EssSurfaceFreezePoint " minOccurs="0"/>

<-- in tenths of degrees C -->

<xs:element name="rain24hrs" type=" ntcip:EssPrecipitation24Hours " minOccurs="0"/>

<-- in tenths of kilograms per square meter (for rain, this is equivalent to tenths of millimeters) -->

<xs:element name="rain1hr" type=" ntcip:EssPrecipitationOneHour " minOccurs="0"/>

<-- in tenths of kilograms per square meter (for rain, this is approximately tenths of millimeters) -->

<xs:element name="rainRate" type=" ntcip:EssPrecipRate " minOccurs="0"/>

<-- rate in tenths of grams per square meter per second (for rain, this is approximately to 0.36 mm/hr) -->

<xs:element name="precipSituation" type=" ntcip:EssPrecipSituation " minOccurs="0"/>

<xs:element name="precipYesNo" type=" ntcip:EssPrecipYesNo " minOccurs="0"/>

<xs:element name="waterDepth" type=" ntcip:EssWaterDepth " minOccurs="0"/>

<-- in centimeters -->

<xs:element name="surfaceWaterDepth" type=" ntcip:EssSurfaceWaterDepth " minOccurs="0"/>

<-- in centimeters -->

<xs:element name="precipStart" type=" DateTimePair " minOccurs="0"/>

<xs:element name="precipEnd" type=" DateTimePair " minOccurs="0"/>

<-- pollution and air quality (formerly another message) -->

<xs:element name="smogAlert" type=" Pollution-SmogAlert " minOccurs="0"/>

<xs:element name="airQualityIndex" type=" Pollution-AirQualityIndex " minOccurs="0"/>

<xs:element name="carbonMonoxide" type=" ntcip:EssCO " minOccurs="0"/>

<-- in parts per million -->

<xs:element name="carbonDioxide" type=" ntcip:EssCO2 " minOccurs="0"/>

<-- in parts per billion -->

<xs:element name="hydroCarbon" type=" Pollution-HydroCarbon " minOccurs="0"/>

<xs:element name="sulfurDioxide" type=" ntcip:EssSO2 " minOccurs="0"/>

<-- in parts per billion -->

<xs:element name="nitricOxide" type=" ntcip:EssNO " minOccurs="0"/>

<-- in parts per million -->

<xs:element name="nitrousDioxide" type=" ntcip:EssNO2 " minOccurs="0"/>

<-- in parts per billion -->

<xs:element name="particulate" type=" ntcip:EssPM10 " minOccurs="0"/>

<-- in parts per million micrograms per cubic meter. -->

<xs:element name="ozone" type=" ntcip:EssO3 " minOccurs="0"/>

<-- in parts per one hundred billion -->

<xs:element name="uvLevel" type=" UVLevel " minOccurs="0"/>

<xs:element name="airQuality" type=" itis:VisibilityAndAirQuality " minOccurs="0"/>

<-- visablity limits -->

<xs:element name="airQualifier" type=" itis:Qualifiers " minOccurs="0"/>

<-- road treatments and conditions -->

<xs:element name="levelofservice" type=" tmdd:Link-level-of-service " minOccurs="0"/>

<xs:element name="status" type=" itis:Closures " minOccurs="0"/>

<xs:element name="drivingRestrictions" type=" itis:WinterDrivingRestrictions " minOccurs="0"/>

<xs:element name="drivingIndex" type=" itis:WinterDrivingIndex " minOccurs="0"/>

<xs:element name="mediantype" type=" tmdd:Link-median-type " minOccurs="0"/>

<xs:element name="mobileFriction" type=" ntcip:EssMobileFriction " minOccurs="0"/>

<xs:element name="pavementConditions" type=" itis:PavementConditions " minOccurs="0" maxOccurs="3"/>

<-- includes data on roadway objects and ice and snow types -->

<xs:element name="pavementTemperature" type=" ntcip:EssPavementTemperature " minOccurs="0"/>

<xs:element name="surfaceTemperature" type=" ntcip:EssSurfaceTemperature " minOccurs="0"/>

<xs:element name="surfaceSalinity" type=" ntcip:EssSurfaceSalinity " minOccurs="0"/>

<xs:element name="pavementtype" type=" tmdd:Link-pavement-type " minOccurs="0"/>

<-- similar to NTCIP.EssPavementType -->

<xs:element name="treatmentForm" type=" ntcip:EssPaveTreatProductForm " minOccurs="0"/>

<xs:element name="treatmentType" type=" ntcip:EssPaveTreatProductType " minOccurs="0"/>

<xs:element name="treatmentAmount" type=" ntcip:EssPaveTreatmentAmount " minOccurs="0"/>

<xs:element name="treatmentWidth" type=" ntcip:EssPaveTreatmentWidth " minOccurs="0"/>

<-- other enviromental data -->

<xs:element name="pressure" type=" ntcip:EssAtmosphericPressure " minOccurs="0"/>

<-- in 1/10ths of millibars, a.k.a. tenths of hectoPascals -->

<xs:element name="solarRate" type=" ntcip:EssSolarRadiation " minOccurs="0"/>

<-- in Joules per square meter, integrated over the 24 hours -->

<xs:element name="dewPoint" type=" ntcip:EssDewpointTemp " minOccurs="0"/>

<-- in tenths of degrees C -->

<xs:element name="other" type=" ntcip:ESS-other " minOccurs="0"/>

<-- ess free text -->

<xs:element name="furtherText" minOccurs="0">

<xs:simpleType>

<xs:restriction base=" xs:string ">

<xs:minLength value="1"/>

<xs:maxLength value="1000"/>

</xs:restriction>

</xs:simpleType>

</xs:element>

<-- misc free text such as NSW messages -->

<xs:element name="furtherData" type=" URL-Link " minOccurs="0"/>

<-- links to images, maps, or other data -->

<xs:element name="tail" type=" Tail " minOccurs="0"/>

<xs:element name="localWeatherInformation" type=" local:WeatherInformation " minOccurs="0"/>

</xs:sequence>

</xs:complexType>

Generated by <oXygen/> XML Editor using a modified version of xs3p that adds schema diagrams and chunking support. Last modified:

Complex Type: WeatherInformation

[Table of contents]
