Documentation for ATIS-Draft-03-00-79

Super-types:	None
Sub-types:	None

Name	CptFleetSubsets
Used by (from the same schema document)	Element cptFleetSubsets
Abstract	no

XML Instance Representation

<...>

<subscriptionInfo> CPTSubscriptionHeader </subscriptionInfo> [1]

<updates-since> CPT-DateTime </updates-since> [0..1]

<defined-groups> [0..1]
Start Sequence [1..30000]

<defined-group> CPTFleetSubsetGroup </defined-group> [1]

End Sequence
</defined-groups>

<deleted-groups> [0..1]
Start Sequence [1..30000]

<deleted-group> CPT-FleetSubset </deleted-group> [1]

End Sequence
</deleted-groups>

</...>

Schema Component Representation

<xs:complexType name="CptFleetSubsets">

<xs:sequence>

<xs:element name="subscriptionInfo" type=" CPTSubscriptionHeader "/>

<xs:element name="updates-since" type=" CPT-DateTime " minOccurs="0"/>

<xs:element name="defined-groups" minOccurs="0">

<xs:complexType>

<xs:sequence minOccurs="1" maxOccurs="30000">

<xs:element name="defined-group" type=" CPTFleetSubsetGroup "/>

</xs:sequence>

</xs:complexType>

</xs:element>

<xs:element name="deleted-groups" minOccurs="0">

<xs:complexType>

<xs:sequence minOccurs="1" maxOccurs="30000">

<xs:element name="deleted-group" type=" CPT-FleetSubset "/>

</xs:sequence>

</xs:complexType>

</xs:element>

</xs:sequence>

</xs:complexType>
