Documentation for ATIS-Draft-03-00-79

Super-types:	None
Sub-types:	None

Name	CCTripCancellationRecord
Used by (from the same schema document)	Complex Type CcCancelTrips
Abstract	no

XML Instance Representation

<...>

<cancelled-trips> [1]
Start Sequence [1..10000]

<cancelled-trip> SCHTripIden </cancelled-trip> [1]

End Sequence
</cancelled-trips>

<day-types> [0..1]
Start Sequence [1..20]

<day-type> SCH-DayType </day-type> [1]

End Sequence
</day-types>

<specific-dates> [0..1]
Start Sequence [1..300]

<specific-date> CPT-Date </specific-date> [1]

End Sequence
</specific-dates>

</...>

Schema Component Representation

<xs:complexType name="CCTripCancellationRecord">

<xs:sequence>

<xs:element name="cancelled-trips">

<xs:complexType>

<xs:sequence minOccurs="1" maxOccurs="10000">

<xs:element name="cancelled-trip" type=" SCHTripIden "/>

</xs:sequence>

</xs:complexType>

</xs:element>

<xs:element name="day-types" minOccurs="0">

<xs:complexType>

<xs:sequence minOccurs="1" maxOccurs="20">

<xs:element name="day-type" type=" SCH-DayType "/>

</xs:sequence>

</xs:complexType>

</xs:element>

<xs:element name="specific-dates" minOccurs="0">

<xs:complexType>

<xs:sequence minOccurs="1" maxOccurs="300">

<xs:element name="specific-date" type=" CPT-Date "/>

</xs:sequence>

</xs:complexType>

</xs:element>

</xs:sequence>

</xs:complexType>
